Our Filter Presses are designed/manufacturered and most efficient to give maximum filteration effeciency of purified liquids. the standard working pressure for filteration is upto 5kgs/sq. cm whereas our designed filter presses can work upto 10 kgs/sq. cm in 100-120 C degree temperature.
| Size | Filtration Area (Sq.Mtrs.) | Capacity Liters/Day | H.P. | No. of Pistons | Size of Plunger Pump |
| 36"x36"x36" Plates x35 frames | 30 | 60000 | 10 | Double | 80 mm |
| 36"x36"x36" Plates | 30 | 40000 | 7.5 | Double | 80 mm |
| 30"x30"x30" Plates x29 frames | 18 | 40000 | 7.5 | Double | 80 mm |
| 30"x30"x30" Plates | 18 | 25000 | 5 | Single | 80 mm |
| 24"x24"x24" Plates x23 frames | 10 | 13500 | 5 | Double | 60 mm |
| 24"x24"x30" Plates | 15 | 12500 | 5 | Double | 60 mm |
| 24"x24"x24" Plates | 10 | 10000 | 3 | Single | 60 mm |
| 18"x18"x18" Plates | 4 | 5000 | 2 | Single | 40 mm |
| 14"x14"x14" Plates | 2 | 3500 | 2 | Single | 40 mm |
| 12"x12"x12" Plates | 1.5 | 2500 | 1 | Single | 30 mm |
